| System |
| Main Processor |
Embedded Processor |
| Network Protocol |
IPv4; RTSP; RTP; TCP; UDP; SIP; P2P |
| OSDP Protocol |
Yes |
| Interoperability |
ONVIF; CGI |
| SDK and API |
Yes |
| Basic |
| Product Type |
Standalone |
| Display Screen |
4.3″ LCD |
| Screen Type |
Capacitive Touchscreen |
| Screen Resolution |
480 (H) × 272 (V) |
| Camera |
2-MP CMOS HD dual-lens camera |
| WDR |
DWDR |
| Light Compensation |
Auto IR |
| Voice Prompt |
Yes |
| Casing |
PC + ABS |
| Function |
| Unlock Mode |
Password, fingerprint, card, remote, face and combination unlock |
| Card Type |
IC card; Desfire card (EV3,Compatible with Dahua card by default) |
| Period List |
128 periods |
| Holiday Period |
128 periods |
| Network Update |
Yes |
| First User Unlock |
Yes |
| Remote Verification |
Yes |
| Restricted List/Trusted List |
Yes |
| Wi-Fi |
Yes |
| Wireless Standard |
IEEE802.11b/802.11g/802.11n |
| Wireless Frequency Range |
2.4 GHz |
| Peripheral Card Reader |
1 × RS–485 card reader; 1 × Wiegand card reader |
| Multi-user Authentication |
Yes |
| Real-time Monitoring |
Yes |
| Web Configuration |
Yes |
| Auto Registration |
Yes |
| RFID |
| Modulation Type |
ASK |
| Frequency Range |
13.56 MHz |
| Max. Transmission Power |
42dBuA/m @10m |
| Network |
| Max. Transmission Power |
≤20dBm@2400-2483.5 MHz |
| Performance |
| Card Reading Distance |
0 cm–3 cm (0″–1.18″) |
| Face Recognition Height Range |
1.1 m– 2.0 m (3.61 ft–6.56 ft) |
| Face Recognition Distance |
0.3 m–1.5 m (0.98 ft–4.92 ft) |
| Face Recognition Accuracy |
99.9% |
| Face Recognition Time |
0.2 s |
| Fingerprint Verification Mode |
1:N |
| Fingerprint Comparison Time |
1.5 s |
| Fingerprint Recognition Time |
0.5 s |
| Read Speed (QR Code ) |
500 ms |
| Code Type |
Paper; Electronic |
| User |
|
| User (Card) Type |
Normal user; VIP users; patrol users; guest user; blocklist user; other user |
| Capacity |
|
| User Capacity |
3,000 |
| Face Image Capacity |
3,000 |
| Card Capacity |
5,000 |
| Fingerprint Capacity |
5,000 |
| Password Capacity |
3,000 |
| Record Capacity |
300,000 |
| Port |
|
| RS-485 |
1 |
| Wiegand |
1 |
| USB |
1 × USB 2.0 |
| Network Port |
1 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
| Exit Button |
1 |
| Lock Control |
1 |
| Door Status Detection |
1 |
| Alarm |
|
| Anti-pass Back |
Yes |
| Tamper Alarm |
Yes |
| Duress Alarm |
Yes |
| Door Sensor Timeout |
Yes |
| Intrusion |
Yes |
| Illegal Card Exceeding Threshold |
Yes |
| Duress Fingerprint |
Yes |
| General |
| Power Adapter |
Standard |
| Power Supply |
12 VDC, 1.5 A |
| Power Consumption |
≤18 W |
| Product Dimensions |
115.0 mm × 118.0 mm × 27.1 mm (4.53″ × 4.65″ × 1.07″) (H × W × D) |
| Packaging Dimensions |
190 mm × 179 mm × 127 mm (7.48″ × 4.65″ × 5.00″) (L × W × H, protection box) |
| Operating Temperature |
–10 °C to +40 °C (+14 °F to +104 °F) |
| Operating Humidity |
0%–90% (RH), non-condensing |
| Operating Environment |
Indoor |
| Net Weight |
250 g (0.55 lb) |
| Gross Weight |
400 g (0.88 lb) |
| Accessory |
Wall mount bracket (included) |
| Installation |
Wall mount; 86 case mount; desk mount |
